Semi Tubular Plate, 4.5 mm Manufacturers

Semi Tubular Plate, 4.5 mm

[ Model No. 640 ]

Product Availability: In Stock

indications

Used as tension band plate in open book pelvic fractures
Comminuted fractures in metaphysis in long bones
For xation of fractures of bula, humerus, radius, ulna, clavicle and tibia

Send Inquiry

Request a Catalog

We supply and ship our products worldwide!

All Our products are CE marked and FDA approved.

Features

Designed in the shape of a half tube
Used in areas where they are subjected to tensile forces
Oval holes allow axial compression
Fixation with Dia. 4.5 mm cortex screws
Available in both Titanium and Stainless Steel

No. of Holes	CODE
No. of Holes	S.S.	Titanium
2	640.02	640.02T
3	640.03	640.03T
4	640.04	640.04T
5	640.05	640.05T
6	640.06	640.06T
7	640.07	640.07T
8	640.08	640.08T
9	640.09	640.09T
10	640.10	640.10T
11	640.11	640.11T
12	640.12	640.12T
